旋盤-コンベンショナル-電子

OPTIMUM OPTIturn L 44

turning diameter 150 mm
swing diameter over bed slide 240 mm
turning dia. in gap 520 mm
greates pass round over bed 446 mm
centre distance 850 mm
Control SIEMENS Sinumerik 828D
spindle turning speed range 10-3.000 U/min
spindle bore 52 mm
feed speeds 15.000 mm/min
turret (x-stations) 8 Pcs VDI30
tailstock quill taper MT MK 4
total power requirement 23 kVA
weight of the machine ca. 2,6 t
Cjdszy Sh Repfx Af Hsrg
dimensions of the machine ca. 2,5 x 1,7x 1,8 m
Very well-maintained machine, barely used—only 270 hours of operation
Can be operated both manually and via CNC control
Original price over €47,000,net

Includes SCHUNK hydraulic jaw chuck with power unit and foot pedal
Includes coolant system
Includes 14 tool holders
Includes USB and LAN ports
Includes automatic guideway lubrication
