Komfi Fullmatic 36

Machine function and use
The FULLMATIC 36 varnishing machine is used for full-scale varnishing of paper sheets. It is equipped with a table for manual feeding the sheets of paper through varnishing module and vacuum conveyor of varnished sheets. On the end of machine is located fixed unloading table. Simple controls of machine allows to continuous regulation of varnishing speed. Varnished sheet of paper is after hardening of varnish using UV radiator fed on unloading table.

TECHNICAL PARAMETERS
Input and output material
Specification of paper:
Max. paper format: 360 x 720 mm
Min. paper format= Manual Feeding: 150 x 200 mm
Min. paper format= Automatic Feeder B3: 200 x 340 mm
Paper weight: 115-350 g/m2
Specification of varnish:
Types of usable varnishes: UV viscosity 30-65s (DIN 4mm flow cup viscosimeter)
Application quantity 4-15 g/m2

Machine parameters
Floor area: 0,8 x 1,9 m
Output parameters
Power - Manual sheets loading: 5-20 m/min
- Automatic sheets Feeder B3: 5-15 m/min
- varnishing speed=UV varnish: 5-20 m/min
- varnishing speed=Water varnish: 5-8 m/min
Varnish temperature: min 20°C
The maximum varnishing speed is dependent on substrate and varnish specifications, ambient temperature, UV lamp power and varnish curing time.

Electrical circuit
Power consumption 5,5 kVA
Nedpfx Ajzzk R Tsh Eown
Machine voltage (basic variant): EU 3xNPE 400/230V 50Hz
Control voltage of machine: 24 VDC
Rated current: 10 A
Recommended value of protection: C 16 A
Lead-in cable: 5G 2,5mm² Cu , 5 m

Pneumatic circut
Pressure pneumatic circuit: 0,6 MPa; Max. 81 l/min (50 l/min)
Recommended connection: Polyurethan (polyamide) tube ø8 mm
Pneumatic circuit of the feeder: over-pressure +0,6 Bar

Control system
The control unit for operating and controlling the machine is developed in Komfi

Operation conditions
The machine is intended for smooth run under temperature conditions ranging from 15 C to 40 C (59°F to 104°F). The acceptable relative air humidity level is from 20  to 80 ,
non-condensing relative humidity. The machine allocation should not be higher than 1000 m above the sea level. It is not allowed to place the machine into explosive or dusty environment.
Working mode
The machine is intended for average monthly capacity according to technical specification.
