HAAS VF-2SSYT
HAAS VF-2SSYT

Name: HAAS VF-2SSYT
Brand: HAAS
Availability: InStock

製造年

2022

状態

中古

所在地

ポーランド

基本データ

機械名:: HAAS VF-2SSYT

メーカー:: HAAS

モデル:: VF-2SSYT

製造年:: 2022

状態:: 使用可能（中古）

稼働時間:: 1,472 h

価格と所在地

所在地:: , ポーランド

電話する

技術詳細

寸法と重量

総重量:

3,810 kg（キログラム）

スピンドル

スピンドルモーター出力:

22,400 ワット

主軸回転速度（最大）:

12,000 回転/分

軸仕様

Ｘ軸移動量:

762 mm

Y軸移動距離:

508 mm

Z軸移動距離:

508 mm

詳細情報

コントローラーメーカー:

HAAS

コントローラモデル:

NGC

テーブル荷重:

680 kg（キログラム）

工具重量:

5,000 g

軸数:

オファーの詳細

広告ID:: A23101851

リファレンス番号:: PL-MIL-HAA-2022-00001

更新:: 最終更新日：21.10.2026

説明

This 3-axis HAAS VF-2SSYT was manufactured in 2022. It features an impressive X-axis travel of 762 mm, Y-axis travel of 508 mm, and Z-axis travel of 508 mm. The machine includes a robust table size of 914 x 457 mm and a maximum table load of 680 kg. If you are looking to get high-quality machining capabilities, consider the HAAS VF-2SSYT vertical machining centre we have for sale. Contact us for further details.

• CNC control: Haas Next Generation Control (NGC)
• 1 GB program memory, 15" LCD
• USB, Ethernet, Wi‑Fi
• HaasConnect remote monitoring
• VNC, DPRNT support
• Early power‑failure detection, program restart from any block
• Run Stop Jog Continue, SafeRun collision mitigation
• Electronic handwheel, memory lock
• Fourth-axis readiness:
• VF‑YT 4th‑axis preparation
• 4AXD: 4th‑axis drive, connections, and wiring
• Note: Rotary table not included
• Software options:
• DWO/TCPC (Dynamic Work Offsets & Tool Center Point Control)
• HSM (High‑Speed Machining with look‑ahead)
• Probing cycles and SO, MACRO, COORD, VPS functions
• Axis travels and feeds:
• Spindle nose to table: 102–610 mm
Kdodj Abap Nspfx Akgeu
• Rapids X/Y/Z: 35.6 m/min
• Max cutting feed: 21.2 m/min
• Max thrust X/Y: 8.87 kN; Z: 13.7 kN
• Worktable:
• 914 × 457 mm
• T‑slot table, 16 mm slots, 125 mm spacing
• Spindle:
• Direct drive, spindle cooling, taper air blast
• Rigid tapping
• Tool changer:
• Side‑mounted ATC, 30 + 1 tools
• Max tool Ø (all pockets): 63.5 mm
• Max tool Ø (adjacent empty): 127 mm
• Tool‑to‑tool: 1.8 s; chip‑to‑chip: 2.4 s
• Accuracy:
• Positioning ±0.005 mm; repeatability ±0.003 mm
• Ballscrew thermal compensation
• Coolant and probing (integrated options):
• P‑COOL: Programmable coolant nozzle
• TSC: Through‑spindle coolant 21 bar, 22 l/min
• WIPS‑R: Wireless workpiece and tool probing system
• Machine features:
• Fully enclosed machining area (sliding front doors, hinged side windows)
• Coolant system with pull‑out tank
• Automatic central lubrication
• Compressed‑air connection
• Machine work light

Additional equipment

• AUGER: Screw‑type chip conveyor
• ACF: Auxiliary coolant filtration system, 25 µm
• COOLANT MAINT PACK: Coolant maintenance package
• COOLANT REFILL: Automatic coolant replenishment system (requires external water supply)
• Enclosure mist extraction / mist condenser (as supplied)
• OIL‑SKIMMER: Coolant tank oil skimmer
• CHIP STRAINER: Mesh filter and metal chip basket set
• LK: Machine lifting kit with lifting accessories and brackets

Technical Specification
Taper Size ISO 40
