マシニングセンター - 垂直

DMG MORI DMC 850 V New Design

x-travel 850 mm
y-travel 520 mm
z-travel 475 mm
Control 840D sl Operate (CELOS) Siemens
turning speed range - main spindle 20 - 14.000 min/-1
power capacity - main spindel 20,3 / 14,5 kW
max. Torque 121 / 84 Nm
Bjdpfx Agszkvtxonewt
tool taper SK 40 DIN69871
table surface area 1.160 x 570 mm
max. table load 1.000 kg
work height max. 800 mm
number of toolpositions 30 pos.
tool taper SK 40 DIN69871
max. tool diameter 80 / (130) mm
max. tool length 300 mm
change-time chip to chip 5,9 sec
rapid traverse ( X / Y / Z ) 42 m/min
feed speeds max. 36.000 mm/min
feed power 6,5 kN
Accelaration 5 m/s²
total power requirement 18 kVA
weight of the machine ca. 6,7 t
dimensions of the machine ca. 5,5 x 3,5 x 2,8 m
CNC-Machiningcenter Vertical
DMG MORI - DMC 850 V New Design

- Operating hours: Power-on: approx. 16,703 h / Spindle runtime: approx. 10,506 h
- Design variant: WHITE

- incl. 4x Smart-Keys (Master, Mode 1, Mode 3, Mode 4)
- WITHOUT tools / WITHOUT Clamping-Units
