BÜRKLE U 40

Robust BÜRKLE multi-layer press / veneer press with two pressing levels and electrically heated press plates.

The separate control of the heating plates allows the temperatures to be adjusted according to the specific application. The press is suitable, among other things, for veneering, gluing, and coating wood-based materials.

The middle heating plate can be heated up to approximately 50 °C, and the maximum temperature of the other heating plates is approximately 100 °C.

Technical data
Year of manufacture: 1989
Pressing area: approx. 1,200 × 800 mm
Opening: approx. 385 mm
Pressing pressure: approx. 40 N/cm²
Number of pressing levels: 2
Iedpfx Anez Dfzvscsbb
Number of press plates: 3
Heating: electric
Max. temperature: approx. 100 °C
Middle heating plate: up to approx. 50 °C
Heating plates can be controlled separately
Equipment
2 pressing levels
3 heating plates
electric plate heating
separate heating plate control
hydraulic pressing system
massive steel construction

The machine is still at the previous owner's location but would be immediately available.
The press can be inspected and tested under power after scheduling an appointment.

Transportation is possible for an extra charge!

Note
The machine will be inspected before sale. For used machines with a year of manufacture of 2009 or earlier, the warranty is excluded when sold to commercial customers. Technical data and equipment may vary. Errors, prior sale, and changes are subject to confirmation. All information without guarantee.
