CNCマシニングセンター-4軸BIMAカット

IMA BIMA Cut 120 (160) / 420

C.N.C. WORKING CENTER 4 axes (X-Y-Z-C)
Goose-neck type, with Numerical Control ICOS-Open.
Software IMAWOP / IMATRONIC - BIMA Fast Cut
Working table with pods and rails. No. 8 Supports (rails) of length mm 1400
Automatic deplacement by CNC (X axis) of the Supports/rails
Automatic deplacement by CNC (Y axis) of the vacuum pods/cups
Automatic Tools Changing System. Tools storage plate (No. 18 folds- positions)
Max. useful working area (X - Y - Z) mm 4200 x 1600 x 60
Min. workpieces dimensions (X - Y - Z) mm 295 x 115 x 14
Max. workpieces dimensions (X - Y - Z) mm 4250 x 2200 x 60
Motorized carpet to evacuate chips and wastes
Separate electric and command cabinet. Total installed power (Kw) 28
Cedpsvxhnujfx Ak Ueha

WORKING GROUPS (TOP):
Vertical electro-spindle 1 x HSK F63 - electro-spindle motor power Kw 14,5 (S6) / Kw 7,5 (S1)
N° 3 Clamps to fix the panel and move it on to the machine (on top of the vacuum pods)
N° 5 Air cushion tables (for the panel parking before being processed)
Vacuum system with suction cups (controlled by CN) to lift panel onto outfeed belts
Workpieces Outfeed system (from Bima Cut) with system with motorized belts
